Commercial Refrigeration
TUC-29F
Single door undercounter freezer on the 190 L footprint. Holds −10 ~ +10 °F on R290, with the same container density as the TUC-29R chiller.
Specifications
| Net capacity | 190 L / 6.7 CUFT |
|---|---|
| Unit dimensions (mm) | 735 × 799 × 966 |
| Temp range | −10 ~ +10 °F |
| Refrigerant | R290 |
| Doors / shelves | 1 door / 1 shelf |
| 40 ft container load | 60 units |
| Packing dimensions (mm) | 783 × 847 × 1029 |
| Packing dimensions (inch) | 30 5/6 × 33 1/3 × 40 1/2 |
Series features
- Freezer temperature class, −10 ~ +10 °F (−22 ~ +6 °C)
- Identical case dimensions to the TUC chiller series
- Custom front panel finish supplied to order
- R290 refrigerant (GWP 3) with Cubigel compressor
- Reversible self-closing doors, magnetic gasket, lock and key
